Features
- Impact resistance, low VSWR
- Pleasing appearance with small size
- Double waterproof design with waterproof ring and silica gel
- Rib reinforcement design for shell
- Suitable for various severe environments
Technical Specifications
| Frequency Range | 902 MHz to 928 MHz | |
| VSWR | ≤1.3 1 | |
| Gain | > 8 DBic | |
| Beamwidth | 70° x 70° | |
| Front-To-Back Ratio | 20 DB | |
| Polarization | Circular Polarization | |
| Relative Humidity | 5 % To 95 % | |
| Impedance | 50 ± 1 Ω | |
| Connector Type | RP TNC Female | |
| Operating Temperature | -40 °F To +185 °F (-40 ℃ To + 85 ℃) | |
| Storage Temperature | -40 °F To +185 °F (-40 ℃ To + 85 ℃) | |
| Size | 7.874 In x 7.874 in x 1.26 in (200 mm × 200 mm × 32mm) | |
| Weight | 2.87 (1.3 Kg) | |
