Features
• Intel Core i3-13100, Quad Core Eight Threads
• 4.50 GHz Turbo Frequency
• Support 4 G, 5 G and Wi-Fi
• 2 x DDR4 slots, Max. 16GB 3200 MHz SO-DIMM
• 1 x M.2 2280 NVME SSD + 4 x SATA
• 6 x intel i226 2.5 GBE NICs
• 1 x HDMI + 1 x DP + 1 x LVDS + 1 x EDP
• 1 x PCIE 16 X + LPT or GPIO
• DC12V
Technical Specification
| Processors | Intel Core i3-13100, Quad Core Eight Threads,4.50 GHz Turbo Frequency |
| BIOS | AMI 128 M BIOS, ACPI supported |
| Memory | 2 x DDR4 So-Dimm 3200 MHz, max 128 GB |
| Storage | 4 x SATA, 6 Gb or s, RAID 0, 15, 10 (B660 only) 1 xM.2 NVME 4x 2280 |
| Ethernet | 6 x Intel I226 2.5 GBE NICs |
| Graphics Card | Intel UHD Graphics Card |
| Power Supply | 19 V 6.3 A or above |
| Expansion | 1 x PCIE 16X, 1 x PCIE 4 X, FPC LPT or GPIO supports 16 GPIO Extension support GPIO strip isolation 16(additional purchase) KB or MS 1 x 7pin needle 0.07 in (2.0 mm) white DuPont seat |
| Working Humidity | 0% RH to 90% RH, relative humidity, and nocondensation |
| Working Temperature | -4 ℉ to 140 ℉ (-20 ℃ to 60 ℃) |
| Other Functions | Auto Wake Up, Auto Power On, Watch Dog |
| Display | VGA, EDP, HDMI, LVDS |
| Package Dimension | 21.1 in x 13.9 in x 5.5 in (536 mm x 355 mm x 141 mm) |
| Gross Weight | 11 lb (5 KG) |
