Features
- Network management, device services, DNS, SNMP, LLDP, ISDP, scheduling, PoE
- Ports management, LAG, VLANs, Address Tables, STP, Multicast, MVR, Auto-VoIP, UDLD, Loop Protect: Network switch functionalities
- Network VLAN features ID, Port, GARP, Protocol, Voice, 802.1 Q
- IEEE 802.3 ad with LACP 12 groups, 8 ports or group
- Quality of Service features 8 queues, rate limits, Diffserv, Auto QoS
- Management Security: Access Control, Denial of Service, Port Authentication, Traffic Control, ACL
- Monitoring Ports, Mirroring, sFlow, Log
- Config Save, Reset, Export, Upgrade, Troubleshoot
Technical Specifications
| Performance | Switching Capacity: 140 Gbps Throughput: 104.16 Mpps MAC Capacity: 16 K |
| Hardware | Flash Memory: 256 MB, DRAM: 2 GB |
| Interface | 12-Port 10 or 100 or 1000 or 2500 Base-T 2-Port 10 G Base-R (SFP or SFP+) 2-Port 10 G Base-T (RJ 45) Port 1-Port Console (With RJ 45) |
| Power | Input: AC 100 V to 240 V AC, 50 Hz to 60 Hz Power Consumption: 30 W |
| PoE | Max PoE Power Budget: 184.8 W Support 12-Ports 10 or 100 or 1000 802.3 af or at or bt Base-T 15.4 W simultaneously on 12 ports 30 W simultaneously on 6 ports |
| Environmental | Operating Temperature: 32 °F to 104 °F (0℃ to 40 ℃) Operating Humidity: 20 % to 85 % RH (Non-Condensing) Storage Temperature: -4 °F to 158 °F (-20℃ to 70 ℃) Storage Humidity: 5 % to 95 % RH (Non-Condensing) |
| Mechanical | Dimension: 1.0236 in x 1.7323 in x 7.0866 in (28 cm x 4.4 cm x 18 cm) (W x H x D) Weight: 8.82 lb (4 kg) |
| Air Flow | FAN: Forced-Air Cooling |
| Transmission Rate | 2.5 G |
| Communication Mode | Full-Duplex |
| Switch Capacity | 140 Gbps |
| Function | LACP, POE, QoS, SNMP, Stackable, VLAN Support |
