Technical Specifications
| Operating Frequency | EU 865 MHz to 868 MHz or US 902 MHz to 928 MHz |
| Chip | Chinese R2000-LTE |
| Read Range | 3.2 ft to 98.4 ft (1 m to 30 m) (depends on tag and antenna) |
| Read Tag | Multiple tags, 1 to 400 tags per s (depends on antenna per tag) |
| Interface (Connector) | USB, Ethernet (10/100 Base-T RJ45), RS-232, RS-485 (Opt.) |
| Protocol | EPC global UHF Class 1 Gen 2 ISO 18000-6C and ISO 18000-6B |
| Antenna Connector | SMA |
| Output Power | 18 dBm to 33 dBm |
| Tag Cache | 1000 tags at 96-bit EPC |
| Shell Material | Cast aluminum |
| Channel Isolation | > 30 dB |
| Output Power Precision | +/- 1 dB |
| Output Power Flatness | +/- 0.2 dB |
| Receive Sensitivity | < -85 dBm |
| Tag RSSI | Supported |
| Antenna Detector | Supported |
| Ambient Temp Monitor | Supported |
| Working Mode | Single/DRM |
| GPIO | 2 inputs, 2 outputs (optically isolated) |
| Power Supply | +12V DC at 2A |
| Power Consumption | < 7W at 30 dBm RF output |
| Heat Dissipation | Air cooling |
| Operating Temperature | -4 °F to +131 °F (-20 °C to +55 °C) |
| Storage Temperature | -4 °F to +185 °F (-20 °C to +85 °C) |
| Humidity | < 95 % 77 °F (+25 °C) |
| Size | 5.03 in x 5.5 in x 0.9 in (128 mm x 140 mm x 24 mm) |
| Weight | 3.9 lb (1.8 kg) |
