Features
- 15.6 in (39.62 cm) TFT LED panel
- Temperature five-wire resistive touchscreen
- Optional Intel Celeron or Core processor
- Aluminium alloy shell, compact fanless design
- Front panel protection class IP65
- Supports full-size Mini PCIe expansion
- Supports USB 3.0
- Support for Windows Embedded and LINUX
- VESA 75 is supported
Technical Specifications
| Touch Screen | Resistive Touch Screen |
| Operating System | Windows 7 32 bit & 64 bit or Windows 8.1 32 bit & 64-bit Windows 10 32 bit & 64 bit or WES7 or Linux |
| Interface | 3 x RS232 |
| Resolution | 1280 x 1024 |
| Memory | 1 x 2.5 in (6.35 cm) SATA Bay, 1 x mSATA Bay |
| Frequency | 2.00 GHz |
| L2 Cache | 2 MB |
| Memory | 1 x SO-DIMM, DDR3L 1333, Max. support 8 GB |
| Storage | 1 x 2.5 in (6.35 cm) SATA bay 1 x mSATA bay |
| Network (LAN) | 1 x 10 Mbps or 100 Mbps or 1000 Mbps Ethernet |
| I/O | 1 x mSATA |
| Expansion | 1x Full size Mini PC le slot |
| Watchdog Timer | 255 timer levels, set up by software |
| Operate System | Windows 7 32 bit & 64 bit or Windows 8.1 32 bit & 64 bit Windows 10 32 bit & 64 bit or WES7 or Linux |
| Input Voltage | 12 V DC |
| Power Consumption | 22 W |
| Display Type | 17 in (43.18 cm) TFT LCD (LED Back light) |
| Max. Resolution | 1920 x 1080 |
| Viewing Angle | 80 (Left), 80 (Right), 80 (Up), 80 (Down) |
| Brightness | 350 |
| Contrast | 1000 |
| Backlight Lifetime | 30,000 hrs |
| Touch Type | High temperature five-wire resistive touch screen |
| Light Transmittance | 80 ±5% at 550 nm wavelength |
| Controller | USB Interface |
| Durability (Touches) | ≥3500 million times |
| Operating Temperature | 32 ⁰F to 122 ⁰F (0 °C to 50 °C) with SSD 32 ⁰F to 104 ⁰F (0 °C to 40 °C with HDD |
| Storage Temperature | -4 ⁰F to 140 ⁰F (-20 °C to 60 °C) |
| Relative Temperature | 10% to 95% at 104 ⁰F (40 °C) |
| Size | 15.20 in x 12.64 in x 2.12 in (386.3 mm x 321.3 mm x 54 mm) |
| Weight | 7.71 lb (3.5 kg) |
