Technical Specifications
| Input Power DC | 11 V to 19 V |
| Power Consumption | < 8 W |
| Input Power AC | 90 V to 240V |
| Power Consumption | < 20 W |
| Net Weight | 6.61386 lb (3 kg) |
| Appearance Size | 19 in (48.26 cm) 1U standard rack mount |
| Wavelength | 1310 nm or 1550 nm or CWDM |
| Output Power | -6 dBm with to 1 dBm |
| Rx sensitivity | <-18 dBm |
| Transmission Distance | SM fiber (6.29 mi) 10+ km MM Fiber (0.18 mi) 300 m |
| Optical Connector | Dup LC or FC or ST or SC or Lemo or Neutrik (optional) |
| Signal Format | SMPTE 424 M, SMPTE 292 M, SMPTE 259 M |
| Data Rate | 270 Mbit/s to 1.48 Gbit/s to 3 Gbit/s |
| Automatic cable | EQ (Belden 1694 A cable) |
| SDI interface | BNC 75 Ohm |
| Interface | 0.1378 in (3.5 mm) headset jack, Datavideo Headset |
| Microphone | Mic inputs with mute and pre-amps |
| Headphone | With amplifier and volume up or down |
| Interface | 0.1378 in (3.5 mm) headset jack, be connected Datavideo ext tally lamp |
| Output | Green or Red 2 colours, on: LED on, off: LED off |
| Work mode | Full Duplex or half duplex |
| Data Rate | 10 Mbps to 100 Mbps (AUTO) |
| Connection terminal | RJ45 |
| Work Temp | -13 °F to 131 °F (-25 °C to 55 °C) |
| Storage Temp | -40 °F to 185 °F (-40 °C to 85 °C) |
| Humidity | 0 % to 95% (non-condensing) |
| Net Weight | 1.7637 lb (800 g) |
| Appearance Size | 7.48 in x 4.33 in x 1.57 in (190 mm x 110 mm x 40 mm) |
