Features
- Based on the New Generation Impinj E710 reader chip
- Support EPC global Gen2 (ISO 18000-6C)
- 33 dBm RF power output
- High performance of anti-collision recognition algorithm
- Real-time monitoring of on-board temperature
- Metal housing, helpful in heat dissipation
Technical Specifications
| RFID Characteristics | |
| Air Protocols | EPC Class 1Gen 2(ISO 18000-6C) |
| Chipset | lmpinj E710 |
| Frequency | 860 MHz to 960 MHz Open frequency, US, CN, EU options |
| Sensitivity | -86 dBm |
| Antenna Port | Four 50 Ω SMA Connectors |
| Output Power | 5 dBm to 30 dBm or 33 dBm (±1 dBm) adjustable. * |
| Connector Interface | 15 pin MOLEX53261-1571 Connector |
| (Power supply, Communication, GPIO) | |
| Tag RSS | Support |
| Antenna Detector | Support |
| Temperature Detector | Support |
| Application Interface | |
| Host API | C, C#/.NET, Java |
| RFID Performance | |
| Max Read Rate | 900 tags per s |
| Max 1ag Nead Distance | ≥ 39.3 ft (12 m) with 8dBi antenna |
| Dimensions | 2.9 in x 1.9 in x 0.3 in (74.8 mm × 48.5 mm × 8 mm) |
