Features
- High density 100 GE or 40 GE convergence, super capacity
- High reliability, long-distance stacking, excellent performance
- High reliability of the entire network, with no perception of service in fault scenarios
- Programmable network devices for flexible customization
- Virtualization hardware gateway for rapid deployment
- Zero configuration deployment of equipment, automatic operation and maintenance
- Intelligent lossless network to meet the high-performance requirements of RoCEv 2 applications
- Cooperate with I Master NCE-FabricIn sight to achieve Artificial Intelligence for IT Operations
- Collaborate with I Master NCE Fabric to achieve minimal deployment of data center networks
Technical Specifications
| Switching Capacity | 6.4 Tbps or 102.4 Tbps |
| Forwarding Performance | 2003 Mpps |
| Number Of Card Slots | 0 |
| Card Type | Fixed card |
| Card Specification | N or A |
| Out-Of-Band Management Port | 1 x GE RJ45 management interfaces |
| Console Port | 1 x RJ 45 interface |
| USB Port | 1 |
| Working Voltage | 600 W AC & 240 V DC power module: AC: 90 V AC to 290 V AC, 45 Hz to 65 Hz; DC: 190 V DC to 290 V DC 1000 W DC power module: -38.4 V DC to -72 V DC 1200 W high-voltage DC power module: 190 V DC to 400 V DC |
| Typical Power Consumption | 203 W (100 % load, half port all copper cable, room temperature, dual AC power supply) 244 W (100 % load, half port full short distance Optical module, normal temperature, dual AC power supply) |
| Long-Term Operating Temperature (°C) | 32 °F to 104 °F (0 ℃ to 40 ℃) 0 mi to 1.12 mi (0 m to 1800 m) The temperature decreases by 33.8 °F (1°C) each time the altitude increases by 0.14 mi (220 m). |
| Storage Temperature (°C) | -40 °F to 158 °F (-40 °C to +70 °C) |
| Relative Humidity | 5 % to 95 % |
| Operating Altitude (m) | Up to 5000 |
| Surge Protection | AC power supply protection: 6 kV in common mode and 6 kV in differential mode DC power supply protection: 4 kV in common mode and 2 kV in differential mode |
| Dimensions (W x D x H) | 17.40 in x 16.53 in x 1.72 in (44.2 cm x 42 cm x 4.36 cm) |
| Weight | 18.96 lb (8.6 kg) |
| IPv6 | IPv 6 Neighbor Discovery (ND) IPv 6 VXLAN over IPv 4 Path MTU Discovery (PMTU) TCP6, IPv6 ping, IPv6 tracer, IPv6 socket, UDP6, and raw IPv6 |
| Traffic Analysis | Net Stream slow |
| VLAN | Adding access, trunk, and hybrid interfaces to VLANs Default VLAN QinQ MUX VLAN GVRP |
| MAC Address Table | Dynamic learning and aging of MAC address entries Static, dynamic, and blackhole MAC address entries Packet filtering based on source MAC addresses MAC address limiting based on ports and VLANs |
| IP Routing | IPv 4 routing protocols, such as RIP, OSPF, IS-IS, and BGP IPv6 routing protocols, such as RIPng, OSPFv 3, IS-ISv 6, and BGP 4+ |
| Programmability | OPS Ansible-based automatic configuration and open-source module release |
| Data Center Interconnect (DCI) | VXLAN mapping, implementing interconnection between multiple DCI networks at Layer 2 |
| SDN | I Master NCE-Fabric |
| Network Convergence | DCBX, PFC, and ETS RDMA and RoCE (RoCEv1 and RoCEv2) FCoE |
| Network Virtualization | VXLAN in routing and bridging modes BGP-EVPN QinQ access VXLAN |
| Device Virtualization | IS tack M-LAG |
