Features
- Fast read & write,Multi tags reading, high performance,
- Long read & write distance
- High gain, low VSWR, Good angular orientation
- Superior Waterproof and anti-corrosive capability,
- Well adapted to climate
- Waterproof IP67
Technical Specifications
| Frequency Range | 920 MHz to 925 MHz |
| Polarization Type | Horizontal |
| Gain | 12 dBi |
| 3dB Beamwidth. H Plan | 30° |
| 3dB Beamwidth. E Plan | 65° |
| VSWR | ≤1.3 |
| Front To Back Ratio | ≥25 dB |
| Input Impedance | 50 Ω |
| Max Input Power | 20 W |
| Lightning Protection | DC Grounded |
| Connector Type | SMA Female |
| Radome Material | PC + ABS |
| Support Pole Diameter | 1.18 in x 2.36 in (30 mm to 60 mm) |
| Radome Colour | White |
| Operating Temperature Range | -40 ºF to +140 ºF (-40 ºC to +60 ºC) |
| Dimensions | 19.69 in x 6.32 in x 36 in (500 mmx 270 mm x 60 mm) |
