Features
- PoE testing, length testing, port flash, ping testing
- Trace targeted cable among lots of unknown cables
- Locate faults for RJ11, RJ45, BNC cable
- Measure cable length accurately
- Voltage detecting function
- Memory and storage function
- Export or upload data from PC
- Lithium battery and colour screen
Technical Specifications
| Indicator | LCD 320 mm (12.59 in) x 240 mm (9.44 in), with back light |
| Cable Test Types | STP, UTP 5E, 6E network, telephone, coaxial cable |
| Maximum Distance Of Wiremap | 2000 m (6561.67 ft) |
| Maximum Distance Of Tracing | 2000 m (6561.67 ft) |
| Maximum Distance Of Cable Length | 1000 m (3280.83 ft) |
| Minimum Distance Of Calibration | 10 m (32.80 ft) |
| Accuracy | 3% (after calibration) |
| Compatible Connectors | RJ11, RJ45, BNC, PING, POE |
| Cable Map Indication | LCD (#1 to #8) |
| Battery Type | 3.7 V lithium battery 1800 mAh |
| Cable Hunting | RJ11, RJ45, BNC |
| Types Of Cable | ≥2 cores |
| Humidity | 32 oF to 158 oF (0 oC to 70 oC) |
| Work Temperature | 50 oF to – 76 oF (10 oC to – 60 oC) |
| Dimension | Emitter 6.81 in x 3.62 in x 1.33 in (173 mm x 92 mm x 34 mm) Receiver 7.20 in x 2.28 in x 1.37 in (183 mm x58 mm x 35 mm) Remote 4.17 in x 1.25 in x 1.18 in (106 mm x32 mm x 30 mm) |
