Technical Specifications
| Frequency Standard | 902 MHz to 928 MHz (US) 865 MHz to 868 MHz (EU) |
| Protocol Standard | ISO18000-6C (EPC GEN2) |
| RF Power | 33 dbm (adjustable) |
| Maximum Query Speed | 800 tags per s |
| Reading Distance | 0 ft to 82.02 ft (0 m to 25 m) (Depends on external antenna and tag) |
| Data Cache Size | 600 pcs at max 128 bits EPC or 180 pcs at max 496 bits EPC |
| Mixed Query | Support simultaneous query of EPC+TID area data |
| Operating Mode | Answer mode Real-time query mode Trigger mode (optional) |
| Judgment Distance | Support output RSSI value |
| Voltage | 12 V 2 A |
| Current Consumption | 0.5 A to 1.2A |
| Communication Interface | Standard Interface: USB, RS232, RS485, TCP/IP & Optional Interface: POE, WIFI |
| GPIO Interface | 2 sets of trigger signal input 2 sets of relay signal output |
| Antenna Port | 4 RP TNC female connectors (TNC reverse female connectors) |
| Operating Temperature | 14 ºF to 140 ºF (-10 ºC to +60 ºC) |
| Storage Temperature | -4 ºF to 167 ºF (-20 ºC to +75 ºC) |
| Equipment Size | 6.69 in x 4.41 in x 0.94 in (170 mm x 112 mm x 24 mm) |
| Equipment Weight | 1.32 lb (0.6 kg) |
