Technical Specifications
| Frequency | 840 MHz to 960 MHz |
| Protocol | EPC C1 GEN 2 & ISO18000 6C |
| Communication | Standard: RS232, RJ45 Optional: RS485, 4G, Wifi |
| Power Supply | DC 12V |
| Antenna | 9 dBi circularly polarized antenna |
| Read Distance | 0 ft to 49.2 ft (0 m to 15 m) |
| Working Mode | Passive |
| Multi-Tags Reading | ≥400 tags per s |
| IP Rating | IP67 |
| Output Power | Adjustable: 5 dBm to 30 dBm |
| Output Power Flatness | ±0.2 dBm |
| Receiving Sensitivity | -82 dBm |
| Radio Frequency Port Standing Wave | ≤1.5 |
| Interface Communication Rate | 115200 bps |
| Material | ABS |
| Working Temperature | -22 °F to 158 °F (-30 °C to +70 °C) |
| Working Humidity | 5% to 95% RH |
| Storage Temperature | -40 °F to 185 °F (-40 ºC to +85 ºC) |
| Size | 11.02 in x 11.02 in x 2.95 in (280 mm x 280 mm x 75 mm) |
