| Frequency | 865 MHz to 868 MHz or 920 MHz to 925 MHz or 902 to 928 MHz |
| Protocol | EPC C1 GEN2 / ISO18000-6C |
| Display | 5.2 in (13.2 cm) IPS FHD 1920 x 1080 |
| Touch Panel | Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported |
| Power | Main battery: Li-ion, rechargeable, 8000 mAh ; Standby: over 500 hrs ; Continuous use: over 12 hrs (depending on user environment) ; Charging time: 3 hrs to 4 hrs (with standard adaptor and USB cable) |
| Expansion Slot | 1 slot for SIM card, 1 slot for SIM or TF card |
| Interfaces | USB 2.0 Type-C, OTG, Octa-core version supports TypeC headphones |
| Audio | Speaker, 2 microphones |
| Keypad | 4 front keys, 1 power key, 2 scan keys, 1 multifunctional key |
| Sensors | Gravity sensor, light sensor, proximity sensor |
| Drop Specification | Multiple 4.9 ft (1.5 m) drops (at least 20 times) to the concrete across the operating temperature range |
| Tumble Specification | 1000 x 1.64 ft (0.5 m) falls at room temperature |
| Sealing | Host IP65 per IEC sealing specifications |
| ESD | ± 15 KV air discharge, ± 6 KV conductive discharge |
| CPU | Cortex-A53 Quad-core 1.45 GHz or Cortex-A53 Octa-core 2.5 GHz |
| RAM + ROM | 3 GB + 32 GB (Quad-core) or 4 GB + 64 GB (Octa-core) |
| Expansion | Supports up to 128 GB Micro SD card |
| Engine | CM2000-1 module based on Impinj Indy R2000 |
| Antenna | Linear polarization (1.8 dBi); circular polarization (4 dBi) |
| Power | 1 W (30 dBm, +5 dBm to +30 dBm adjustable) ; 2 W Optional (33 dBm, for Lati America, etc.) |
| Read Or Write Ranges | > 22.9 ft (7 m) (linear polarization, outdoors); > 68.8 ft (21 m) (linear polarization, indoors) ; > 32.8 ft (10 m) (circular polarization, outdoors); > 82.02 ft (25 m) (circular polarization, indoors) |
| Reading Rates (Circular Polarization) | >200 tags per s (circular polarization) |
| Note | Ranges and rates depend on tags and environment |
| WLAN | IEEE802.11 a/b/g/n, 2.4G per 5G dual-band, internal antenna |
| WWAN (China) | 2G: 900 MHz or 1800 MHz ; 3G: 900 MHz or 1900 MHz or 2000 MHz or 2100 MHz ; 4G: B1, B3, B5, B38, B39, B40, B41 |
| WWAN (Europe) | 2G: 850 MHz or 900 MHz or 1800 MHz or 1900 MHz ; 3G: 850 MHz or 900 MHz or 1900 MHz or 2100 MHz ; 4G: B1, B3, B5, B7, B8, B20, B40 |
| WWAN (America) | 2G: 850 MHz or 900 MHz or 1800 MHz or 1900 MHz ; 3G: 850 MHz or 900 MHz or 1700 MHz or 1900 MHz ; 4G: B2, B4, B7, B12, B17 |
| WWAN (Others) | Depending on the country’s ISP |
| Bluetooth | Bluetooth 4.0, BLE |
| GNSS | GPS/AGPS, GLONASS, BeiDou; internal antenna |
| Operating Temp. | 4 °F to 122 °F (-20 °C to 50 °C) |
| Storage Temp. | -40 °F to 158 °F (-40 °C to 70 °C) |
| Humidity | 5 % RH to 95 % RH noncondensing |
| Dimensions | 6.46 in x 3.15 in x 0.96 in (164.2 mm x 80.0 mm x 24.3 mm) |
| Weight | 23.07 oz (654 g) |
