Technical Specifications
| Measure Principle | TDR |
| Measurement Parameters | Soil Moisture and Temperature Value |
| Moisture Measuring Range | 0% to 100% (m³ / m³) |
| Moisture Measuring Resolution | 0.1% |
| Moisture Measurement Accuracy | ±2% (m³ / m³) |
| Temperature Measuring Resolution | 32.18 °F (0.1 °C) |
| Temperature Measurement Accuracy | ±31.1 °F (±0.5 °C) |
| Measuring Area | Cylinder with a diameter of 2.76 in (70 mm) and height of 2.76 in (70 mm) centered on the center probe |
| Output Signal (RS485) | RS 485 (Standard Modbus-RTU protocol, device default address: 01) |
| Output Signal (Wireless) | LORA / LORAWAN (EU 868 MHz, 915 MHz), GPRS, WIFI, 4G |
| Supply Voltage | 10 V DC to 30 V DC |
| Maximum Power Consumption | 2 W |
| Working Temperature Range | -40 °F to 176 °F (-40 °C to 80 °C) |
| Stabilization Time | <1 second |
| Response Time | <1 second |
| Tube Material | PVC Material |
| Waterproof Grade | IP 68 |
| Cable Specification | Standard 39.37 in (1 m) |
