Features
- Industrial grade ARM 9 processor, 300 MHz frequency
- 128 MB DDR 3 SD RAM,128 M flash
- Support 2 wire high-speed 10 M or 100M
- Support 2 or 4 wire RS 485 serial communication interface
- Built-in real-time clock (RTC), temperature sensor
- Independent hardware encryption circuit to protect user IP
- Built-rich communication protocol library to support the electricity
- ProfiNET, EtherNet, BACnet, SNPx
- Modbus TCP or IP, MQTT, OPC-IE and other communication protocols
- Built-in WEB server, support for remote development, configuration
- CAN interface bidirectional optical isolation CAN2.0 interface standard
- Expandable 4-128G TF memory card
- Rugged metal shell and internal circuit “three defenses” treatment
Technical Specification
| Support | Expandable 4 to 128 G TF memory card |
| System connection method | RJ 45, 4G, 3G, 2G, WIFI, etc |
| Uplink protocol | ProfiNET, EtherNet, BACnet, SNPx, etc |
| Type | modbus gateway |
| Total port | 4 RJ 45 ports |
| Protocol Support | Standard or Special Protocol |
| Downlink protocol | Modbus RTU, Modbus TCP, Profibus-DP |
| Storage | 8 G TF card |
