Features
- Deep penetration, the signal penetrates 5 to 6 walls
- In urban transmission distance exceeds 2 km and in suburban 8 km
- High compatibility
- Open interface
- We chat config
- Network diagnostic and clear display of gateway parameters
- Rich interfaces with DC, Terminal, Type C and PoE power supply
- Stable operation -40 °F to 185 °F (-40 °C to °85 C) & 0% RH to 99.9% RH
Technical Specifications
| Spreading factor | SF 7 to SF 12 |
| Frequency band | 433, 470, 868, 915, 923 |
| Transmit power | +30 dBm max |
| Receiving sensitivity | -135 dBm (@ SF 10 @ BW 125 KHz) |
| Routing channel | 8 Rx, 1 Tx |
| Power supply interface | 9 V DC to 36 V DC (typical: 12 V DC) |
| PoE power supply | 38 V DC to 57 V DC (typical: 48 V DC) |
| Average operating power consumption | 1 W |
| Configuration interface | BLE |
| Configuration method | Wechat Applet |
| LoRa Communication | Drive SX 1302, 8 channels upstream, 1 channel downstream |
| Data return | Ethernet or WiFi |
Reviews
There are no reviews yet.
