Technical Specifications
| Spreading Factor | SF 7 to SF 12 |
| Frequency Band | 433 MHz, 470 MHz, 868 MHz, 915 MHz, 923 MHz |
| Transmit Power | +30 dBm max |
| Receiving Sensitivity | -135 dBm |
| Routing Channel | 8 Rx to 1 Tx |
| Communication Distance | 8 km |
| Power Supply Interface | 9 V to 36 V Dc and (typical, 12 V Dc) |
| Power Consumption | 1 W |
| Configuration Interface | BLE |
| Configuration Method | WeChat Applet |
| Lora Communication | Drive S X 1302, 8 channels upstream, 1 channel downstream |
| Data Return | Ethernet and Wi Fi |
| Working Humidity | 0 % RH to 99.9 % RH |
| Working Temperature | -40 °F to 185 °F (-40 ℃ to + 85 ℃) |
