Features
• 5G NR or LTE cat20 or HspA+
• WIFI supports 802.11 b or g or n or ac, dual Wi-Fi band
• Gigabit Ethernet connection
• Support VPN client and server
• Support TCP OR IP, UDP, FTP (optional)
• HTTP and other network protocols
• Support remote management, SYSLOG, SNMP, TELNET, SSHD, HTTPS
Technical Specification
| Max. LAN Data Rate | 1000 Mbps |
| With Modem Function | Yes |
| Wi-Fi Supported Frequency | 2.4 G & 5 G |
| 2.4G Wi-Fi Transmission Rate | 300 Mbps |
| Standards And Protocols | Wi-Fi1.77lb(802.11), Wi-Fi802.11b,Wi-Fi802.11n,Wi-Fi802.11ac,Wi-Fi802.11a |
| Encryption Type | WPA2-Enterprise, WPA, WEP |
| LAN Ports | 1 |
| Supports WDS | Yes |
| Supports WPS | Yes |
| Wi-Fi Transmission Standard | 802.11 ac |
| Wired Transfer Rate | 10 Mbps or 100 Mbps or 1000 Mbps |
| Private Mold | Yes |
| Function | Firewall, QoS, VPN |
| WAN Ports | 1 x 10 Mbps or 100 Mbps or 1000 Mbps |
| 5G Wi-Fi Transmission Rate | 1000 Mbps |
| CPU | Industrial 32-bit processor |
| Network | 5 G + 4 G LTE + 3 G (HSPA+ or HSPA orUMTS) |
| WIFI | Wi-Fi 2.4 G or 5 G |
| Interface | 1 WAN + 1 LAN + 1 x RS232 or RS485 or CAN |
| Antenna | Cellular:4 x SMA |
| Speed | Download: 3.4 Gbps Upload: 350 Mbps |
| Item | 5G NR router |
| 5G NR | 5G NR: n1, n3, n5, n7, n8, n20, n28, n38,n41, n77, n78, n79 5G NR: n2 or n5 or n7 or n12 or n25 or n41or n66 or n71 or n78 (Optional) |
| LTE | LTE: B1, B2, B3, B5, B7, B8, B20, B28, B34,B38, B39, B40, B41, B42, B43 LTE: B2 or 4 or 5 or 7 or 12 or 13 or 14 or 17or 25 or 26 or 29 or 30 or 66 or 71 or B41 or42 or 48 (Optional) |
| HSPA+ | 850 MHz or 900 MHz or 1900 MHz or 2100 MHz |
| CPU | Industrial 32-bit processor |
| Flash | Nor flash 16 MB (64 MB optional), and flash 128 MB |
| DDR3 | 521MB |
| TF card | 8 GB or 32 GB, optional |
| Update interval | 5 GHz |
| Location | 2.5 m CPE SBAS：2.0 m CPE |
| Sensitive | Follow：-160 dBm Re-capture：-160 dBm Cold start：-146 dBm |
| Dimensions | 1.3 in x 4.3 in x 1.6 in (35 mm x 110 mm x 43 mm) |
