Features
- 16 ports MMCX connector
- High Performance of anti-collision recognition
- Real-time Monitoring of On-board temperature
- Aluminum housing, helpful in heat dissipation
- Smart size and fully packaged
Technical Specifications
| Air Protocols | EPC Class 1 Gen 2 |
| Antenna Ports | 16 ports, 50 Ω MMCX Connector |
| Output Power | 5 dBm to 30 dBm (±1 dBm) adjustable |
| Work Mode | Fixed and hop frequency optional |
| Connector Interface | 15 pin SFW 12R and 1 STE 1 LF connector |
| Max Read Rate | ≥700 tags/s |
| Max Tag Read Distance | 8 dBi antenna |
| Communications | UART serial port (RS 232), Baud rate 9600 bps to 115200 bps |
| GPIO | Optional, 2 inputs (DC 0 V to 3.3 V) 2 output (DC 0 V to 3.3 V) |
| Power Supply | Input Voltage 3.6 V DC 5.0 V |
