Features
• CPU: IPQ8071A ARM Cortex A53s @ 1.4 GHz
• Qualcomm (IPQ8071A, QCN5024, QCN5054, PMP8074, QCA8075)
• 4 Gb SDRAM 2 Gb NAND FLASH, 64 Mb QSPI FLASH
• Wi-Fi 802.11 a or b or g or n or ac or ax, 4 x 4 MIMO, DBDC
• WIFI technology: 802.11 ax 3.5 Gbps
• USB: 2 USB x USB 3.0
• Ethernet: 5 x 10 Mbps or 100 Mbps or 1000 Mbps
• 1 x 1 Gbs or 2.5 Gbs or 5 Gbs or 10 Gbs
• 1 x SD card +2 x mini pcie
• 1 x Micro SIM Card Slot, support 5 G IoT Module
• Power: DC 12 V or 2 A;
• Antenna: 12 x Wi-Fi external antenna
Technical Specification
| Max. LAN Data Rate | 1000 Mbps |
| With Modem Function | Yes |
| Wi-Fi Supported Frequency | 2.4 G and 5 G |
| 2.4G Wi-Fi Transmission Rate | 600 Mbps |
| Standards And Protocols | Wi-Fi 1.77lb(802.11 g),Wi-Fi 802.11b,Wi-Fi 802.11n,Wi-Fi 802.11ac,Wi-Fi 802.11a |
| Encryption Type | WPA2-PSK, WPA2, WPA2-Enterprise,WPA-PSK, WPA, WPA-Enterprise,WPA2-Personal, WPA-Personal |
| LAN Ports | 4 |
| Supports WDS | Yes |
| Supports WPS | Yes |
| Wi-Fi Transmission Standard | 802.11 ac |
| Wired Transfer Rate | 10 Mbps or 100 Mbps or 1000 Mbps |
| Function | Firewall, QoS, VPN |
| WAN Ports | 1 |
| 5G Wi-Fi Transmission Rate | 2167 Mbps |
| Chipset | IPQ8074 or IPQ8071 |
| RAM | 1 GMByte DDR3L |
| FLASH | Nor flash 32 Mn and flash 256 MByte |
| WIFI Technology | 802.11 ax 4.8 Gbps |
| USB | 2 x USB3.0 |
| Ethernet | 5 x 10 Mbps or 100 Mbps or 1000Mbps 1×1 Gbs or 2.5 Gbs or 5 Gbs or 10 Gbs |
| Power | DC 12 V or 2 A; POE: 802.3 at POE+48V or 0.5 A |
| Antenna | 12 x Wi-Fi external antenna |
| Dimensions | 11 in x 6.5 in x 0.9 in (280 mm x 166 mm x 24 mm) |
