Features
- Support tags conforming to standards EPC global UHF ISO-18000-6C (EPC G2), TK900;
- Frequency range 902~928MHZ (or customized);
- Support multi communication interfaces (LAN, RS232, RS485, Wiegand26/34);
- 4 SMA antenna ports, 7dbi circular polarization antenna, the height of antenna adjustable;
- RF output power 20 ~ 30dBm adjustable, support auto, command, trigger work modes;
- Reliable industry structure design, workable in varied severe environment.
Technical Specifications
| Read Range | 236.22 in (0 m to 6m) |
| Communication Interface | RJ45 RS232 (WiFi or 4G optional) |
| Keyword | Gate reader |
| Power Supply | AC220 V ± 10% |
| Machine Power | 20 W |
| Function | Sound and light alarm, optional binocular recognition camera |
| Appearance | Body-silver, gray, panel-off-white |
| Equipment Material | Alloy profile; acrylic surface material |
| Output Power | 0 to 33 dBm (adjustable) |
| Single Package Size | 18.11 in x 13.77 in x 11.02 in (46 cm X 35 cm X 28 cm) |
| Single Gross Weight | 8.81 oz (0.250 kg) |
| Chip | Impinj R2000 |
| Working Frequency | 902 to 928 MHz or 865 to 868MHz |
| SDK | C++, JAVA, C# |
| Software | Provides a DEMO (Reading and writing tags automatically) |
| IProtocol | ISO18000 6C or EPC C1G2, ISO18000 6B, GB or T29768 to 2013 (expandable support) ISO15693 |
| Clock | Real time saved when power off |
| Frequency Method | Fixed or hopping |
| Material | Alloy profile; Acrylic surface material |
| Working Method | Sound and light alarm |
| Working Temperature | 14 °F to 122 °F (-10 ℃ to 50 ℃) |
