Technical Specifications
| Display | Tough 5.5 in (13.9 cm) TFT to LCD (720 x 1440) touchscreen with backlight |
| Backlight | LED backlight |
| Expansions | 2 PSAM, 2 SIM, 1 TF |
| Battery | Rechargeable li-ion polymer, 3.8 V, 7200 mAh |
| CPU | Cortex-A73 2.0 GHz octa-core |
| Operating System | Android 10.0 |
| Storage | 4 GB RAM or 64 GB ROM, MicroSD (max 256 GB expansion) |
| Humidity | 5 % RH to 95 % RH (non-condensing) |
| Drop Specifications | 5 ft (1.5 m) drop to concrete across the operating temperature range |
| Sealing | IP65, IEC compliance |
| ESD | ±15 kv air discharge, ±8 kV direct discharge |
| SDK | Handheld-Wireless Software Development Kit |
| Language | Java |
| Environment | Android Studio or Eclipse |
| 4G | TD to LTEBand 38 or 39 or 40 or 41 FDD to LTEBand 1,2,3,4,7,17,20 |
| 3G | WCDMA (850 MHz or 1900 MHz or 2100 MHz); |
| 2G | GSM or GPRS or Edge 850 MHz or 900 MHz or 1800 MHz to 1900 MHz） |
| WIFI | 2.4G or 5G dual frequency, conforming to IEEE802.11 a, b, g, n or ac. |
| Bluetooth | Comply with Bluetooth4.1 |
| Symbologies | PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes, US PostNet, USPlanet, UK Postal, Australian Postal, Japan Postal, Dutch Postal. etc. |
| Resolution | Rear 13 megapixel, front 5.0 megapixel |
| Lens | Auto-focus with LED flash |
| Protocol | ISO 14443A&15693, NFC-IP1, NFC-IP2 |
| R/W Range | 0.7 in x 1.9 in (2 cm to 5 cm) |
| Frequency | 865 MHz to 868 MHz or 902 MHz to 928 MHz or 13.56 MHz |
| Protocol | EPC C1 GEN2 or ISO 18000-6C |
| Antenna Gain | Circular antenna (4 dBi) |
| R/W Range | 65.6 ft (20 m) (depend on tags and environment) |
| Protocol | ISO 7816 |
| Baudrate | 9600, 19200, 38400,43000, 56000, 57600, 115200 |
| Slot | 2 slots (maximum) |
| Standard arrangement | One lithium battery one charging head One Type-c charging cable |
| Matching | Charging stand |
| Operating Temperature | -4 °F to 122 °F (-20 ℃ to 50 ℃) |
| Storage Temperature | 68 °F to 158 °F (20 ℃ to 70 ℃) |
| Dimension | 6.69 in x 3.14 in x 1.10 in (170 mm x 80 mm x 28 mm) |
| Weight | 17.6 oz (500 g) |
