Overview
The Inventory Master UHF RFID Integrated Reader with LED Strip can be widely used in logistics tracking, commodity inventory, cargo sorting, vehicle management, personnel management, asset management, medical systems, cold chain management, temperature monitoring, power monitoring, anti-counterfeiting systems and production process control and many other applications.
Features
- Developed with independent IP
- UHF chip-based modules
- Modular design for varied functions
- Consistent SDK support
- Stable core components
- Flexible UHF operation modes
- Keyboard mode supported
- POE and network support
- Multi-OS compatibility
- Multi-language support
- Multi-protocol compatibility
- Custom development and OEM/ODM services
Technical Specifications
| Antenna Frequency | 865 MHz to 940 MHz |
| RF Frequency | 865 MHz to 868 MHz or 902 MHz to 928 MHz (Can be customized) |
| Protocol | ISO 18000-6C/6B |
| FHSS Or Fix Frequency | Support |
| RF Out Power | 33 dBm |
| Step Power | 1 dBm |
| RSSI | Support |
| Reading Distance | ≥ 65.6 ft (20 m) Under 9 dBi circularly polarized antenna, full power setting, standard E41 test card |
| Reading Speed | ≥ 500 per S |
| Interface | Standard: USB, RS232, RS485/Wiegand, RJ45 (TCP/IP, UDP) At option: WiFi, Bluetooth, 4G DTU |
| Baud Rate | 38400 bps or 59600 bps or 115200 bps |
| Read Value | TID + EPC per USER |
| Mode | Command, polling or trigger |
| Operating Voltage | DC 12.0 V (+9 V to 24 V) |
| Operating Current | ≤ 800 mA or DC 12 V |
| Standby Current | ≤ 200 mA or DC 12 V |
| POE | Support |
| Performance | High performance |
| SDK | Support |
| IAP Firmware Update | Support |
| Custom Development | Support |
| Operating Temperature | -4 °F to 131 °F (-20 °C to 55 °C) |
| Storage Temperature | -40 °F to 185 °F (-40 °C to 85 °C) |
| Operating Humidity | < 95 % RH 77 °F (+25 °C) non-condensing |
