Technical Specification
| Forwarding Rate | 23.9 Mpps |
| Transmission Mode | Store and Forward |
| Packet Buffer Size | 4.1 |
| Exchange capacity | 56 G |
| MAC Table Size | 8 K |
| Delay Time | <10 μs |
| Ethernet Port | 10 or 100 or 1000 Base-T(X) auto speed control, full or half duplex and MDI or MDI or X auto-adaptation |
| Power indicator | PWR (green) |
| Optical port | FX (green) |
| Network port indicator | Yellow (1000 or POE) Green (Link) |
| Input Voltage | DC 10 V to 58 V or AC 100 V to 240 V 50 Hz to 60 HZ |
| Connector | 6 bit 0.2 in (5.08 mm) |
| Full Load | <10 W |
| Protection Mechanism | Overload protection Reverse connection Protection Redundancy protection |
| MTBF | > 100,000 hrs |
| Operating Temperature | -40 °F to 185 °F ( -40 °C to 85 °C) |
| Storage Temperature | -40 °F to 185 °F (-40 °C to 85 °C) |
| Ambient Relative Humidity | 5 % to 95 % (non-condensing) |
| Shell | IP40 protection, aluminium alloy housing |
| Dimension | 7.12 in x 6.14 in x 1.85 in (181 mm x 146 mm x 47 mm) |
| Weight | 2.20 lb (1 kg) |
