Features
- Automatic frequency correction
- Automatic gain control
- Fast wake-up
- Frequency hopping
- Highly configurable data packet handler
- SMA Antenna
Technical Specifications
| Working Voltage | 1.8 V to 3.7 V |
| Acceptable Current | 10 mA to 14 mA |
| Transmit Current | 120 mA at 20 dBm, 90 mA at 17 dBm, 29 mA at 13 dBm |
| Operating Frequency | 868 MHz / 915 MHz |
| Transmit Power | +20 dBm |
| Receive Sensitivity | -139 dBm at LoRa & 62.5 KHz & SF = 12 & 146 bps |
| -136 dBm at LoRa & 125 KHz & SF = 12 & 293 bps | |
| -118 dBm at LoRa & 125 KHz & SF = 6 & 9380 bps | |
| -123 dBm at FSK & 5 KHz & 1.2 Kbps | |
| Frequency Error | + / -15 KHz |
| FIFO Space | 64 Bytes |
| Data Rate | 1.2 Kbps to 300 Kbps at FSK |
| 0.018 Kbps to 37.5 Kbps at LoRa | |
| Interface Form | SPI |
| Sleep Current | 0.2 uA at SLEEP |
| 1.5 uA at IDLE | |
| Operating Temperature | -40 °F to 185 °F (-40 °C to 85 °C) |
