Features
- Monochrome LCD
- Adjustable Contrast
- High Resolution
- Wide Compatibility
Technical Specifications
| Compliance | IEC61010-1 for live systems up to 150 V CAT IV with fused test lead set |
| Output Pulse | 5 volts peak to peak into open circuit |
| Pulse Widths | Determined by range and cable, set with 3 user-selectable steps in Manual mode |
| Velocity Factor | Variable from 0.2 to 0.99 in steps of 0.01 |
| Battery Type | Five LR6 (AA) type batteries, Manganese alkali or nickel metal-hydride cells |
| TX Null | Automatic |
| Power Down | Automatic after 5 minutes with no key press |
| Backlight | Stays on for 1 minute with no key press |
| Range | 30 ft, 75 ft, 300 ft, 750 ft, 3000 ft, 7500 ft, 15000 ft (10 m, 25 m, 100 m, 250 m, 1000 m, 2500 m, 5000 m) |
| Accuracy | ±1% of range + pixel at 0.67 VF (conditional on correct velocity factor) |
| Resolution | 0.32 ft (0.1 m) |
| Input Protection | 1% of range |
| Battery Life | Up to 14 hours (typical) |
| Display | 256 x 128-pixel Graphics LCD |
| Dimensions | 9.05 in x 4.52 in x 1.88 in (23 cm x 11.5 cm x 4.8 cm) (LBD) |
| Weight | 1.32 lb. (0.6 kg) |
