| Frequency | 865 MHz to 868 MHz or 902 MHz to 928 MHz |
| Protocol | EPC class1 Gen2 or ISO18000-6c |
| Type | UHF RFID Reader |
| Card Type | UHF Day |
| Interface | Serial Port |
| Reading Distance | > 32.8 ft (10 m) |
| Application | Parking, Hospital, Library, Company, Bank, Store |
| Application Software Platform | API (c++, c#) development kit (can be customized) |
| GPIO | 1 relay output, 1 trigger input |
| Power Supply | 220 V AC input, + 12 V or 2 A adapter DC output |
| Integrated Antenna | 12 dBi linear polarization |
| SDK | C#, C++, Delphi, VB, Java |
| Communication | Standard: RS232, RJ45, Wiegand; optional: 4G or WiFi Bluetooth or USB |
| Achievement | 30 dBm (adjustable in 1 dBm increments with the FDY demo software |
| Shell Material | ABS + PC |
| Specification | 23.6 in x 23.6 in x 19.6 in (60 cm x 60 cm x 50 cm) |
| Front Antenna Housing Color | Grey |
| Rear Antenna | Aluminum Die Casting |
| Installation | Holding Tree |
| Radio Frequency | Independent R&D technology for the financial year |
| Read or Write Area | Reading range 32.8 ft to 82.0 ft (10 m to 25 m), writing range > 29.5 ft (9 m) |
| Group Read Rate | 1 pc EPC Tag |
| Serial Rate | 9600 bps to 115200 bps |
| Price RJ45 | 10 Mbps |
| GPIO | 1 relay output, 1 trigger input |
| Reading The Ad | Buzzer |
| Electricity Consumption | 1 W |
| Power Supply | 220 V AC input, +12 V or 2 A adapter DC output |
| Application | Windows-based API development kit and application routine |
| SDK | C#, C++, Delphi, VB, Java |
| Protection Level | IEC IP65 |
| Light Protection | Direct current |
| Standard | Bracket, power supply |
| Humidity | 5 % to 95 % Relative Humidity, non-condensing |
| Operating Temperature | -13 °F to 158 °F (﹣25 °C to﹢70 °C) |
| Storage Temperature | -22 °F to 176 °F (﹣30 °C to﹢80 °C) |
| Size | 17.5 in X 17.5 in X 1.5 in (445 mm × 445 mm X 40 mm) |
| Weight | 12.1 lb (5.5 kg) |
