Features
- Octa-core processor
- 5 in (13.9 cm) IPS display
- WIFI roaming
- Powerful scan code
- GMS android 10.0
Technical Specifications
| Frequency | 860 MHz to 960 MHz |
| Protocol | EPC C1 GEN2 or ISO 18000-6C |
| R or W Range | 6.5 ft to 49.2 ft (2 m to 15 m) |
| Private Mold | No |
| Color Depth | 64-bit |
| Interface Type | type c |
| Max Paper Size | Other |
| Software Development Kit (SDK) | With free sdk |
| Color | Orange |
| Operating System | Android 10.0 |
| Barcode Scanner | 1D or 2D Barcode Scanner |
| Camera | 5 M AF |
| Display | Gorilla Glass 5.5 in (13.9 cm) IPS Gorilla Glasstouch screen |
| RAM Or ROM | 2 GB +16 GB or 4 GB +64 GB |
| Battery Capacity | 4800 mAh 3.8 V |
| Functions | 1D or 2D Scanner NFC RFID Reading |
| Screen | Industrial grade multi-touch capacitive screen |
| Expansions | 1 Sim, 1 TF, 1 PSAM |
| Charging | 1 Type-c interface |
| Indicator Light | Network indicator, Charging indicator |
| Keyboard | Scan button, function button |
| GPS | GPS, accuracy of (5 m) 16 .4 ft |
| CPU | MTK 2.0Ghz Octa-core 64-bit processor |
| Storage | RAM of 2 GB ROM 16 GB RAM of 4 GB ROM 64 GB |
| Expansions | Support 256GB Micro TF |
| 4G | TD-LTE Band 38 or 39 or 40 or 41FDD-LTEBand 1, 2, 3, 4, 7, 17, 20 |
| Standard | 1 x Power Supply; 1 x Lithium Polymer Battery; 1 x Type-C data cable |
| WIFI | 2.4 GHz or 5.8 GHz Dual Frequency, IEEE 802.11 a/b/g/n/ac. Support Wi-Fi roaming function |
| Bluetooth | Bluetooth 4.0 |
| Front Camera | 5.0 megapixel |
| Back Camera | 13.0 megapixel and 20.0 megapixel for optional With flash and auto focus |
| Battery Capacity | 3.8 V 4800 mAh |
| STBY Time | Theoretical 360 hrs |
| Charging | Less than 5 hrs (Support fast charging function） |
| Barcode (Optional） | |
| 1D Barcode | 1D laser engine Symbol SE955 Symbologies All major 1D barcodes |
| 2D Barcode | 2D CMOS Imager Zebra SE4710/Zebra SE2100/etc Symbologies PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QRcode, MicroQRcode, Aztec, MaxiCode, PostalCodes, USPostNet, USPlanet, UKPostal, AustralianPostal, JapanPostal, DutchPostal, etc. |
| LF | Frequency 125 KHz or 134.2 KHz (FDX-B/HDX) Protocol ISO 11784 & 11785 R/W Range Touch – 0.7 in (2 cm) (tags and environment affected) Frequency 13.56 MHz Protocol ISO14443A/B ISO15693, NFC-IP1，NFC-IP2, etc. R/W Range Touch 0.7 in to 3.1 in (2 cm to 8 cm) (tags and environment affected) |
| Working Time | 14 hrs (100 % charge state) |
| Dimension | 6.5 in x 3.1 in x 1.0 in (166 mm x 79 mm x 27 mm) |
| Weight | 15.1 oz (430 g) |
