Overview
Discover our cutting-edge UHF RFID reader with superior specifications: Die-cast aluminum body, adjustable output power, and extensive protocol support.
Technical Specifications
| Body Material | Die-cast aluminum |
| Input Voltage | DC 12 V to 18 V |
| Standby Mode Current | <80 mA |
| Sleep Mode Current | <100 uA |
| Max Operating Current | 700 mA +/-5% at DC 12V Input |
| Interface Protocol | EPC global UHF Class 1 Gen 2 / ISO 18000-6C / ISO 18000-68 |
| Spectrum Range | 902 MHz to 928 MHz, 865 MHz to 868 MHz |
| Supported Regions | US, Canada, Europe, Mainland China, Taiwan, Korea, Malaysia |
| Output Power | 0 dBm to 33 dBm |
| RF Connector | TNC/RP-TNC |
| Output Power Precision | +/- 1 dB |
| Output Power Flatness | +/- 0.2 dB |
| Receive Sensitivity | < -85 dBm |
| Peak Inventory Speed | > 700 tags per s |
| Tag Buffer Capacity | 1000 tags at 96-bit EPC |
| Tag RSSI | Supported |
| Antenna Detector | Supported |
| Ambient Temp Monitor | Supported |
| Working Mode | Single/DRM |
| Host Communication | RS-232 or TCP/IP |
| GPIO | 2 input optical coupling & 2 output coupling |
| Baud Rate | 115200 bps or 38400 bps |
| Heat Dissipation | Air cooling |
| Operating Temperature | -4 °F to +185 °F (-20 °C to +85 °C) |
| Storage Temperature | -4 °F to +185 °F (-20 °C to +85 °C) |
| Humidity | 5 % RH to 95 % RH (non-condensing) |
| Dimension | 9.45 in x 7.09 in x 1.10 in (240 mm x 180 mm x 28 mm) |
