Technical Specifications
| Operating Voltage | 3.7 V to 5 V |
| Standby Mode Current | <50 mA (EN high level) |
| Sleep Mode Current | <100 uA (EN low level) |
| Operating Current | 1.2A +/-10 % |
| RF Channel | Single channel |
| RF Connector | MMCX |
| Interface Connector | Molex 53261-1571 |
| RF Connector Material | Gold-plated brass |
| PCB Material | Pogers FR4 gold-plated |
| Shield Material | Aluminium |
| Air Interface Protocol | EPC global UHF Class 1 Gen 2 or ISO 18000-6C or ISO 18000-6B |
| Spectrum Range | 860 MHz to 960MHz |
| Supported Regions | US, Canada and other regions following U.S. FCC Europe and other regions following ETSI EN 302 208 with & without LBT regulations Mainland China, Japan, Korea, Malaysia |
| Supported Regions | 0 to 33 dBm |
| Output Power Precision | +/- 1 dB |
| Output Power Flatness | +/- 0.2 dB |
| Receive Sensitivity | < -85 dBm |
| Peak Inventory Speed | > 700 tags per seconds |
| Tag Buffer Size | 1000 tags @ 96 bits EPC |
| Tag RSSI | Supported |
| Antenna Detector | Supported |
| Ambient Temp Monitor | Supported |
| Working Mode | Single or DRM |
| Host Communication | TTL Uart port |
| GPIO | 2 inputs optical coupling 2 outputs optical coupling |
| Max Baud Rate | 115200 bps |
| Heat Dissipation | External cooling fin |
