Technical Specifications
| Frequency | 902 MHz to 928 MHz (US）865 MHz to 868 MH (EU) |
| Protocol | ISO18000-6C (EPC GEN2) |
| RF Output Power | 0 dbm to 33 dbm (adjustable) |
| Reading Speed | 200 tags per seconds |
| Data Cache | 600pcs @ 128bits EPC |
| Reading Distance | 0 ft to 49.21 ft (0 m to 15 m) |
| Anti-Collision | Quick polling and inventory of multiple antenna ports |
| Operating Mode | Active mode or Answer mode |
| RSSI | Support |
| Standard Interface | USB, RS232, RS485, TCP or IP |
| Optional Interface | POE (Mode A/B af), Wi-Fi |
| GPIO Interface | 2 sets of GPI & 2 sets of GPOS |
| Antenna Port | 4 TNC reverse female connectors |
| power Supply | 12 V 2 A |
| Current Consumption | 0.5 A to 1.2 A |
| IP Protection Level | IP65 |
| SDK | Demo software, API, examples, user manual |
| Development Language | Support C#, Delphi, java, Python, VB, etc. |
| Firmware Version | Support online upgrade |
| Size | 7.22 in x 6.36 in x 1.02 in (184 mm x 161.7 mm x 26 mm) |
