Technical Specifications
| Chipset | Impinj R2000 |
| Spectrum Range | 860 MHz to 960 MHz (customized optional) |
| Protocol | EPC global Class1 Gen2/ISO 18000-6C |
| Transmission Mode | FHSS or fixed frequency |
| Output Power | 33 dBm |
| Operating Modes | -Passive work mode -Real-time inspection work mode |
| Anti-Collision Modes | -EPC – TID – USER – EPC+TID |
| Peak Inventory Speed | >700 tags per s |
| Rf Output Power | 33dBm |
| Tag Buffer Size | 1000pcs at 96bits EPC |
| Data Read/Write Operation | -Support EPC and TID area data read/write operation |
| Power Supply | -Low power consumption design -Single +12V power supply -Optional POE power supply mode |
| Communication Interfaces | -RS232 – USB – RJ45 (TCP/IP) -WIFI (optional) – 4G (optional) -POE (optional) |
| Input / Output Control | -2 channels of input control (5V signal) -2 channels of output control (5V signal) -2 channels of relay control |
| Software & SDK | -Provide free Window, Linux & Android DEMO software -SDK for testing and facilitating further development |
| Tag Support | -Support temperature sensor RFID tag -Support normal RFID tag |
