Features
- The reader is compatibility with few protocol
- Logistics and warehouse management
- Production line management
- Product security detection
- Other application: club management, library, consumption etc
Technical Specifications
| Working Frequency | 902 MHz to 928 MHz or 865 MHz to 868 MHz |
| Protocol | ISO18000-6C (EPC C1 GEN2) |
| Antenna Gain | 3 dBi circular polarization |
| Communication Port | Left USB to serial port or Right USB to keyboard input |
| Software & SDK | DEMO and C#, VC, VB, Java, DELPH, etc., |
| Encryption | Can be directly encrypted, copy prevention |
| Reading Range | Stable reading 23.62 in to 31.49 in(600 mm to 800 mm) |
| Writing Range | Stable writing 0 in to 0.39 in (0 mm to 10 mm) |
| Power | USB |
| Shell Material | ABS |
| Output Power | 0 dBm to 18 dBm ± 1 dBm |
| Working Temperature | – 4 ºF to + 167 ºF(- 20 ºC to + 75 ºC) |
| Storage Temperature | – 40 ºF to + 185 ºF(- 40 ºC to + 85 ºC) |
| Item Size | 4.72 in x 3.07 in x 1.10 in(120 mm x 78 mmx 28 mm) |
| Net Weight | 7.05 oz (200 g) |
