Technical Specifications
| Frequency Range | 840 MHz to 960 MHz, adjustable |
| Protocol | EPC C1G2, ISO18000-6B/C |
| Frequency Band | GB 920 MHz to 925 MHz, 840 MHz to 845 MHz; FCC 902 MHz to 928 MHz; |
| Optional Frequency Band | Please tell our sales which band you want before ordering: ETSI 865 MHz to 868 MHz; JP 916.8 MHz to 920.4 MHz; TW 922.25 MHz to 927.75 MHz; ID 923.125 MHz to 925.125 MHz; RUS, 866.6 MHz to 867.4 MHz; TEST, 802.75 MHz to 998.75 MHz; JP_LBT, 916.8 MHz to 920.8 MHz |
| Communication Protocol | COM |
| Reading Distance | (0 cm to 30 cm), adjustable |
| Antenna Gain | 0 dBi |
| Working Mode | Fixed frequency or frequency hopping optional |
| RF Output Power (Port) | 33 dBm ±1 dBm (MAX) |
| Recognizing Speed | > 400 times per S |
| Communication | COM port or HID |
| RS232 | Baud rate support 9600, 19200, 115200 (default), 460800 optional; |
| Material | Aluminum |
| Power Supply | USB power supply |
| Power Consumption | 15 W (output power 33 dBm) |
| Operating Temperature | -4 °F to 140 °F (-20 ºC to +60 ºC) |
| Storage Temperature | -40 °F to +185 °F (-40 ℃ to +85 ℃) |
| Working Humidity | < 95 % 77 °F (+25 °C) |
| Dimension | 5.039 in x 4.528 in x 0.787 in (128 mm x 115 mm x 20 mm) |
| Net Weight | 10.58 oz (300 g) |
