Features
• Adopt micro-UHF antenna
• Completely independent intellectual property design
• Working frequency: 840 MHz to 960 MHz (customized)
• Support protocol: EPC C1 GEN2/ ISO 18000 -6C
• USB power supply for mobile phones
• Working current is about 200 mA
• LED light, red indicates card reading status
• Maximum reading distance is about 1.97 in to 0.39 in
• Provide Android mobile DEMO and development
Technical Specifications
| Protocol | ISO18000-6C (EPC GEN2) |
| Frequency | 865MHz to 868 MHz (EU) 902MHz to 928MHz (US) |
| Interface | USB 2.0 (Free drive) |
| RF Power | 18 dBm to 26 dBm (adjustable) |
| Tow Modes | Write tags mode (read and write) Keyboard mode (only read) |
| Read Speed | Single tag average reading < 6 ms per 64 bits (set by software) |
| Read Distance | 19.7 in (50 cm) (depends on tag) |
| Write Distance | 7.87 in (20 cm) (depends on tag) |
| Read Tip | Buzzer and LED |
| Built-In Antenna | 3 dBi |
| Power Supply | Mini USB |
| Way of Working | FHSS |
| Working Temp | -4 °F to + 176 °F (-20 °C to + 80 °C) |
| Size | 4.5 in x 2.9 in x 0.86 in (115mm x 75mm x 22mm) |
| N/W | 4.23 oz (120 g) |
