Overview
Explore our 125 kHz RFID antennas with NFC chip, versatile protocols, long reading distances, and reliable firmware upgrades.
Technical Specifications
| NFC Radio Frequency Chip | ZC100 |
| Protocol | ISO 18000-6C |
| Air protocol | ISO 15693 or ISO 14443A |
| Working Frequency | 13.56MHz |
| Reading Distance | 4.44 in (110mm) 2.36 in (60mm depending on label) |
| Write Distance | 4 in (100mm) 2 in (50mm depending on label type) |
| Label RSSI | Support |
| Antenna | PCB integrated antenna |
| Communication Interface | RJ 45 RS 232 RS 485 |
| Protocol | Modbus RTU TCP UDP protocols |
| Heating Device | Low temperature automatic heating (minus 5°) is optional (determined according to the project site environment) |
| communication Rate | Serial port communication rate 9600 bps to 115200 bps, RJ 45 communication rate 10 Mbps or 100 Mbps |
| working Status | LED indicator light buzzer |
| Reliable Firmware Upgrades | Scalable upgrade mechanism |
| General Purpose Input or Output | 2 way input 2-way output |
| Application Software Interface | Provide API development kit and C# and Java application routines |
| Power Supply | Working voltageDC9 to 24V |
| Power Consumption | Maximum power consumption 3W, maximum starting current 1A |
| Communication Harness | Industrial connection tail wire one for five |
| Humidity | 5 % to 95 %, non-condensing |
| Operating Temperature | – 10 °F to 152 °F (- 4 °C to + 85 °C) |
| Size | 3.74 in x 3. 74 in x 1.57 in (95 mm x 95 mm x 40 mm) |
| Weight | Approx 2.42 lb (1.1 kg whole set) |
