Features
- Max battery life 15 years
- Exceptional IP68 proof
- Install in any position
- No air measuring
- Detecting pipe leaks
- The unique patent design
Technical Specifications
| Type | Ultrasonic meters |
| Flow Rate | R250 |
| Measurement Range | 0.01 to 25 m³/h |
| Measurement Range Ratio | Q3/Q1 = 100/125/160/200/250/400 |
| Accuracy Rating | Class 2 |
| Pressure Rating | MAP16 |
| Pressure Loss Rating | ≤0.063 MPa |
| Flow Measurement | Reverse flow measurable |
| Data Storage | Daily storage, daily freeze, monthly storage, monthly freeze, annual storage (customizable) |
| Remote Transmission Method | Optical, M-BUS, RS485, NB-IoT, LoRaWAN, 4G, Pulse, wM-BUS (configured on demand) |
| Power Supply | DC 3.6V Lithium Battery |
| Battery Life | ≥6 years |
| Working Environment | Temperature: -13 to 131 °F (-25 to 55 °C) |
| Installation Position | Horizontal to Vertical |
| Stream Field Sensitivity | UODO |
| Temperature Rating | T30, T50, T70 |
| Size | DN15: 6.50 in L x 3.68 in H x 3.35 in W (165 mm x 93.5 mm x 85 mm) DN20: 7.68 in L x 3.84 in H x 3.35 in W (195 mm x 97.5 mm x 85 mm) DN25: 8.86 in L x 3.98 in H x 3.35 in W (225 mm x 101 mm x 85 mm) |
