Features
- Wind sensors hidden for cleaner design, ideal for snow/rain
- No calibration required for accuracy
- Real-time measurement with no start-up wind speed
- Highly integrated, maintenance-free, no moving parts
- ASA plastic shell for UV and radiation protection
- Clip-type probe design for secure transport
Technical Specifications
| Item | Range | Resolution | Accuracy | Principle |
| Wind Speed | 0 to 60 m/s | 0.01 m/s | ±0.3 m/s | Ultrasonic |
| Wind Direction | 0° to 360° | 1° | ±2° | Ultrasonic |
| Temperature | -40°F to 140°F (-40°C to 60°C) | 0.018°F (0.01°C) | ±0.54°F (±0.3°C) | Diode |
| Humidity | 0% to 100% RH | 0.1% RH | ±3% RH | Capacitance |
| Pressure | 4.35 psi to 15.95 psi (300 hPa to 1100 hPa) | 0.0015 psi (0.01 hPa) | ±0.007 psi (±0.5 hPa) | Piezoresistive |
| Thermoelectric Radiation | 0 W/m² to 2000 W/m² | 0.1 W/m² | ≤±3.1% | Thermocouple |
| Cumulative Daily Radiation | 0 W·h/m² to 65535 W·h/m² | 1 W·h/m² | – | – |
| PV Module Temperature | -58°F to 212°F (-50°C to 100°C) | 0.18°F (0.1°C) | ±0.9°F (±0.5°C) | – |
| Customized Support | OEM, ODM, OBM, software reengineering |
| Material | ASA engineering plastic |
| Output | RS485 |
| Supply | DC 12 V |
| Communication | Modbus RTU |
| Power | 0.8 W |
| Protection Grade | IP65 |
| Feature | Highly integrated, compact |
| Application | Meteorology, intelligent industry |
| Certificate | CE, RoHS, EMC, LVD, ISO9001, ISO14001 |
| Option | Electronic compass |
| Patent | 1. Hidden sensor at top, patent no. ZL 2020 2 3215713.X., 2. Continuous frequency conversion ultrasonic principle, patent no. ZL 2020 2 3215649.5., 3. Wind Speed, Wind Direction, Ambient Temperature, Relative Humidity, Barometric Pressure, noise, PM2.5, PM10, 8 parameters in 1, patent no. ZL 2020 2 3215649.5. |
| Operation Temperature | -40 °F to 185 °F (-40 °C to 85 °C) |
