Features
- Millimeter-wave radar, with a measurement accuracy of up to ±1mm, and a minimum blind area of 0.1m.
- The smaller antenna size satisfies the measurement of more working conditions.
- A variety of lens antennas, smaller launch angle, more concentrated energy, stronger echo signal, under the same industrial and mining conditions, compared to Other radar products have higher reliability.
- With stronger penetrability, it can be used normally even if there is adhesion and condensation.
- The dynamic signal range is larger, and the measurement of low dielectric constant medium is more stable.
- A variety of measurement modes, the radar reaction time in the fast measurement mode is less than 1S.
Technical Specifications
| Material | Stainless Steel |
| Measuring Range | 0.1 m to 30 m (3.9 ft to 98.4 ft) |
| Pressure | Max. 2.5 MPa (362.6 psi) |
| Antenna Material | Stainless Steel / PTFE |
| Process Connection | Flange ≥ DN50 (2 in); Thread 2 in NPT |
| Power Supply Voltage | 24 V DC |
| Output Signal | (4 to 20) mA + HART / RS485 |
| Blind Area | Antenna ends |
| Microwave Frequency | 26 GHz |
| Display Regulation | 0.1 cm (0.04 in) |
| Power Source Options | Two-wire system / DC 24 V Four-wire system / AC 220 V Six-wire system / DC 12-24 V |
| Signal Output Options | Two-wire system: 4 to 20 mA / HART protocol Four-wire system: 4 to 20 mA / HART protocol Six-wire system: 4 to 20 mA / HART protocol |
| Measuring Medium | Liquid |
| Process Pressure | -0.1 MPa to 2.5 MPa (-14.5 psi to 362.6 psi) |
| Antenna Size | 1.7 in (4.4 cm) lens antenna |
| Accuracy | 0.08 in (±0.2 cm) |
| Protection Level | IP67 |
| Frequency | 80 GHz |
| Launch Angle | 6° |
| Shell Material | Aluminum / Plastic / Stainless Steel |
| Process Temperature | -40°F to 392°F (-40°C to 200°C) |
| Single Package Dimensions | 39.4 in x 1.2 in x 1.2 in (100 cm x 3 cm x 3 cm) |
| Weight | 55.1 lb (25 kg) |
