Features
- Digital MODBUS RS485 interface
- 90° scattering measurement
- Great ambient light rejection
Technical Specifications
| Use | Aquaculture, water treatment |
| Mounting Type | Put into water |
| Theory | Optical principle |
| Output | RS485, 0 V to 5 V, 0 V to 10 V, 4 mA to 20 mA output |
| Wireless Output | LoRa, LoRaWAN (EU868 MHz, 915 MHz), GPRS, NB-IoT |
| Power/Output | 9 V to 36 V DC, RS485 MODBUS RTU |
| Measurement Mode | 90° IR scattered light method |
| Housing Material | POM + 316 Stainless Steel |
| Measurement Range | 0.01 NTU to 400 NTU or 2000 NTU or 4000 NTU |
| Measurement Accuracy | ±5% or 0.5 NTU, whichever is greater |
| Pressure Resistance | ≤0.3 Mpa |
| Calibration | Standard liquid calibration, water sample calibration |
| Cable Length | Standard 32.8 ft (10 m), can be extended to 328 ft (100 m) |
| Thread | G3/4 |
| Installtion | Immersion type |
| Application | General applications, rivers, lakes, environmental protection, etc. |
| Waterproof Rating | IP68 |
| Measuring Temperature | 32 °F to 113 °F (0 °C to 45 °C) |
| Dimensions | Diameter 1.96 in (5 cm) × Length 8.77 in (22.3 cm) |
