Features
- Automatic angle measurement: No need for angle adjustments during installation, ensuring quick and easy setup.
- IP65 protection grade: Suitable for long-term outdoor use.
- Automatic heating function: Activates when temperature drops below the set threshold, ensuring stable measurement.
- Compatibility with weather station: Displays data on a large LED screen and uploads to a free cloud platform for remote monitoring.
Technical Specifications
| Mounting Type | Pole mounted |
| Type | Laser sensor |
| Power Supply | 10 V to 30 V DC |
| Output Signal | Ethernet, WIFI, LORA, RS485 |
| Range | 0.16 ft to 4.92 ft (0.05 m to 1.5 m) |
| Accuracy | ±1 mm |
| Resolution | 1 mm |
| Laser Type | 635 nm, <1 mw |
| Laser Class | II Class |
| Single Measurement Time | 0.05 s to 1 s |
| Spot Size | Spot 5 mm @ 32.8 ft (10 m), line spot 0.11 in × 5.9 in (0.3 cm × 15 cm) @ 32.8 ft (10 m) |
| Working Environment | -40 °F to 176 °F (-40 °C to 80 °C), Humidity: 0% RH to 95% RH (non-condensing) |
