Technical Specifications
| Use | Monitor | |
| Mounting Type | Magnet, Ceiling and Wall Mounting | |
| Features | Acoustic temperature Vibration sensor | |
| Output | Wireless | |
| Amplifier Type | – | |
| Voltage – Supply | 12 V DC | |
| Output Type | 1 V to 10 V | |
| Current – Supply | 25 mA | |
| Frequency | 5.8G | |
| Acceleration | Number of axes | 3-axis |
| Sensing unit | MEMS | |
| Amplitude range | ±50 g Peak Z axis and ±16 g peak X and Y axis | |
| Measurement accuracy | ±5% (160 Hz) Z axis, ±5% (160 Hz) X and Y axis | |
| Lateral sensitivity (typical value.) | 3% (100 Hz) | |
| Data Acquisition | Acceleration frequency range | Z axis: 0.1 Hz (±3 dB) to 10 kHz (±3 dB) X and Y axis: 0.5 Hz (±3 dB) to 1.6 kHz (±3 dB) |
| Acceleration amplitude range | ±50 g | |
| ADC accuracy | 32-bit ADC | |
| Sampling Rate | 1 KHz to 51.2 KHz | |
| Sampling length | 2 K bytes to 2 M bytes | |
| Measuring Interval | 5 minute indicator and 2 hour time domain waveform | |
| Output mode | Total value, effective value and spectral time domain waveform | |
| Voiceprint Acquisition | Sampling rate | 44 KHz |
| Signal-to-noise ratio | 66 dBA | |
| Sensitivity | -38 dBV | |
| Output Manner | The default sound bay is dB. The voiceprint waveform is optional | |
| Synchronous RPM Frequency Monitoring | Monitoring coverage | 0 Hz to 100 Hz |
| Measurement accuracy | ±0.5 Hz (only for motor equipment) | |
| Wireless Communication | Network topology | star |
| Radio frequency standard | IEEE 802.15.4 | |
| Radio frequency range | 2.4 GHz ISM band | |
| Firmware upgrade mode | Gateway over-the-air upgrade | |
| Encryption/Security | 128 bit AES Encrypted transmission | |
| RF output power | 5 dBm (max) | |
| Wireless communication distance | 382.76 yard (350 m) visual barrier free distance (actual distance depends on obstacle block, gateway antenna type and direction, site location selection, etc.) | |
| Battery | Battery Type | Replaceable C 3.6 V disposable lithium subbattery
Warning: Only the following battery models can be used: EVE ER26500 or Xeno Energy XL-145F, and requires secondary processing |
| Life Span | Works for 3 years according to the default configuration definition | |
| Compliance With Regulations | Electromagnetic compatibility standard | IEC 61326-1 |
| Wireless spectrum | ETSI EN 300 328 | |
| Secure | Meet the technical requirements of micro power short range radio equipment | |
| Explosion proof safety | ExiaIICT4 Zone 0 IIC gas environment | |
| Authentication | Meet CE requirements | |
| Supporting Gateway | Intellilink | SG5XX gateway |
| Temperature Acquisition | Measuring range | -40 °F to 248 °F (-40 °C to 120 °C)
(Device surface temperature, can not be confused with the product operating temperature, operating temperature is limited by the battery, etc., the battery is a distance from the bottom sensing part) |
| Accuracy | 33.8 °F (1 °C) | |
| Working Condition | Operating Temperature | -40 °F to 158 °F (-40 °C to 70 °C)
(Working at or beyond the limit temperature for a long time can affect battery life and even damage the monitor) |
| Mechanical Parameter | Corrosion resistance | Stainless steel body, soluble resistant nylon material |
| Anti-drop | 4.92 ft (1.5 m) drop to concrete | |
| Airframe material | 304 stainless steel base and reinforced impact resistant fiberglass nylon upper cover | |
| IP level | IP68 Waterproof and dustproof grade | |
| Outside dimension | Height: 3.34 in (8.5 cm); Diameter: 1.33 in (3.4 cm) | |
| Fixed Hole | M10 × 1 mm × 8 mm | |
| Weight | 7.6 oz (218 g) (battery included) | |
