Features
- Moisture proof
- Lightning protection
- Surge protection
- Low power design
- Strong applicability
- Various signal output methods
Technical Specifications
| Range (MH2O) | 0 ft to 164 ft (0 m to 50 m) |
| Power Supply Voltage | 3.6 V lithium battery power supply DC 12 V to 30 V external power supply |
| Accuracy | ± 0.5 % FS +1 % FS |
| Long-Term Stability (1Year) | ≤ 0.2 % FS |
| Overload Pressure | 200 % FS |
| Working Frequency Band | 470 MHz or 868 MHz |
| Sampling Frequency | 10 s to 12 h can be set (default 10 s) |
| Sending Frequency | 1 min to 1440 min can be set |
| Communication Protocol | Private protocol or LoRaWAN (Class A, OTAA mode activation) |
| Degree Of Protection | Contact unit: IP68, Industrial housing: IP65 |
| Housing Material | Liquid contact material: 304 stainless steels, Industrial housing: aluminum die casting or ABS |
| Power Consumption | Sleep current: S20 uA, sampling current: S5 mA (for 1 s) |
| Current | Average communication current: < 60 mA (for 15 s), online current: 10 mA (for 60 s) |
| Battery Capacity | 12000 mAh |
| Display Mode | 6-segment LCD display |
| Storage Environment | Temperature: – 40 °F to 176 °F (- 40 °C to 176 °C), humidity: 0 % to 95 % RH |
| Temperature | 14 °F to 158 °F (- 10 °C to 70 °C) |
| Working Temperature | – 4 °F to 140 °F (- 20 °C to 60 °C) |
| Dimensions | 0.9 in x 0.7 in x 0.1 in (24 mm x 19 mm x 2.8 mm) |
