| Material | ABS |
| Color | 17.78 cm (7-in) true color TFT LCD |
| Power Supply | 100 to 240 VAC, 24VDC |
| Application | Industrial |
| Function | Record sensor data |
| Output Signal | RS485 Optional |
| Relay Output | 6-way |
| Accuracy | Real-time display: ±0.2% F.S, Recall accuracy: ±0.2% F.S. (Thermocouple cold end error removal) |
| Channels | Max 16 channels |
| Measurement Range | 0 to 9999 |
| Weight | 4.41 lbs. (2 kg) |
| Screen | 7 in (17.78 cm) true-color TFT LCD (800 x 480 dot matrix) |
| Processor | High-performance ARM Cortex-M3 32-bit RISC core |
| Storage Module | Parallel NAND FLASH chips for historical data, serial FRAM for key parameters |
| Distribution Output | Supports up to 3 transmitters, isolated distribution 24VDC, each group ≤ 60mA |
| Transmitter Output | Up to 4 channels standard current output, load capacity 750 Ω (max), long-distance signal transmission |
| Relay Alarm Output | Up to 6 relay alarm outputs, contact capacity 1A @ 250 VAC / 1A @ 30 VDC (customizable) |
| Communication Interface | RS232C and RS485, supports Modbus RTU protocol, multiple baud rates (1200 to 57600) |
| Print Interface | RS232C direct connection to micro printer, baud rate 1200 |
| Recording Capacity | 64 / 128 / 192 / 248MB (flash capacity optional) |
| Recording Interval | 1 to 240 seconds, divided into 11 files (1, 2, 4, 8, 12, 24, 36, 60, 120, 180, 240 seconds) |
| Data Backup And Transfer | Supports USB 1.1 / USB 2.0, 1G to 32GB U disk |
| Power Supply | AC 100-240V, 50/60Hz, DC 24V, 12V (specific power to be indicated when ordering) |
| Power Failure Protection | Built-in memory protection, permanent storage after power off |
| Clock Protection | Integrated hardware clock for accurate operation after power down |
| Relative Humidity | 0% to 85% R.H (without condensation) |
| Altitude | <(2000m) 6,561.68 feet (unless specified otherwise) |
| Instrument Net Weight | ≤ (1.5 kg) 3.31 lbs |
| Thermocouple Cold End Compensation Error | ±3.6°F (±2℃) |
| Operating Temperature | 14 °F to 122 °F (-10 ℃ to 50 ℃) |
