Technical Specifications
| CPU | RK3568J/RK3568B2, 22nm |
| RAM | 1/2/4 GB LPDDR4X |
| Storage / ROM | 8/16/32 GB eMMC |
| Ethernet Ports | 3 x RJ-45, 10/100M, ESD Level 3, EFT Level 3 |
| USB Ports | 2 x USB 2.0 HOST, high-speed 480 Mbps, ESD Level 3 |
| IO Slots | X series: 1 slot (RS485, CAN, RS232, RS422, DI, DO, GPIO)Y series: 2 slots (RS485, CAN, RS232, RS422, DI, DO, Relay output, AI, AO, PT100, PT1000, TC) |
| Mini PCIe | 1, supports Bluetooth, WiFi, 4G module |
| SIM Slot | 1, Nano SIM |
| Antennas | 2, for 4G/WiFi/GPS |
| Communication Interfaces | RS485, Ethernet, USB, Bluetooth, RS232, Wi-Fi, PCIe, 4G |
| Software | Node-Red, Python, Docker, C#, MySQL, SQLite |
| Power Input | DC 9–36V |
| Installation | DIN35 rail mounting, wall mounting |
| Debug Port | 1 x Micro USB |
| SD Slot | 1 |
| Product Type | Embedded IoT Edge Gateway |
| Dimension | 110 x 83 x 42 mm or 110 x 83 x 48 mm (4.33 x 3.27 x 1.65 in / 4.33 x 3.27 x 1.89 in) |
| Weight | Not specified |
