Technical Specification
| ROM | 8 GB or 16 GB or 32 GB |
| RAM | 1/2/4GByte LPDDR4X |
| CPU | RK3568J/RK3568B2, 22 nm ARM Cortex-A55 cores (64-bit) with a clock speed of 1.4 GHz in normal mode and up to 1.8GHz RK3568B2 clock speed 2.0 GHz NPU: 1 TOPS Supports INT8/INT16/FP16/BFP16 Supports TensorFlow/PyTorch/Caffe/MXNet deep learning frameworks Encoder: Supports 4K@60fps H.265/H.264 video decoding Decoder: Supports 1080P@60fps H.265/H.264 video encoding |
| ETH | RJ-45, 1~3, 3x100M, ESD Level 3, EFT Level 3 |
| USB | 2x USB2.0 HOST(USB1, USB2), supports high-speed 480Mbps, ESD Level 3 |
| Input Voltage | DC 9 V to 36 V |
| IO Slot | X series IO board slot: 1, X series IO board, support RS485, CAN, RS232, RS422, DI, DO, GPIO, etc Y series IO board slot: 2, Y series IO board, support RS485, CAN, RS232, RS422, DI, DO, Relay output, AI, AO, PT100, PT1000, TC, etc. |
| Grounding | 1-pin GND terminal |
| LED | 1 power indicator light |
| Antenna | 2 For 4G or WIFI or GPS |
| Material | Aluminium alloy casing & stainless steel |
| SD Slot | 1 SD |
| SIM Slot | 2 Slot |
| Power | 24 V |
| HDMI | 1 HDMI |
| Dimensions | 4.33 in x 3.26 in x 1.65 in(110 mm x 83 mm x 42 mm) |
